| Product Name |
Gemini S |
| Case Form Factor |
Mid-Tower |
| Dimensions (WxHxD) |
210 x 495 x 463 (mm)
8.27 x 19.49 x 18.23 (in) |
| Motherboard Formats |
Mini ITX / Micro ATX / ATX / CEB / E-ATX |
| I/O Panel |
USB3.0 x 2, USB2.0 x 1, Mic x 1 / Audio x 1, RGB Control Button |
| 3.5″ Drive Bay |
2 |
| 2.5″ Drive Bay |
5+2 (converted from 3.5″ drive bays) / (2 SSD trays included) |
| Expansion Slots |
7 |
| Cooling Fan Support |
Front |
120mm x 3 |
| Top |
140mm x 2 / 120mm x 3 |
| Rear |
120mm x 1 (pre-installed) |
| PSU Cover |
120mm x 1 (for HDD Cooling) |
| Maximun Number of Fans |
8 Max. |
| Water Cooling Support |
Front |
360mm / 240mm / 120mm |
| Top |
360mm / 280mm / 240mm / 140mm / 120mm |
| Rear |
120mm |
| Max. Graphics Card Length |
410 (mm) / 16.14 (in)
(Horizontal graphics card slots are compatible with RTX 3090/3080/3070.) |
| Max. CPU Cooler Height |
175 (mm) / 6.89 (in) |
| PSU |
Standard ATX PS2 |
| Max. PSU length |
200 (mm) / 7.9 (in) |
| Onboard Lighting System |
Trelux Lighting with Addressable RGB LEDs and Dynamic Lighting Effects in the Front Panel |
| Cable Management |
Yes |
