UPS PROLINK Super Fast Charging 650A 350WATT

Name: UPS PROLINK Super Fast Charging 650A 350WATT - Expert-Zone
SKU: UPS-PRO-700-650VA
Price: 35.00 USD
Availability: InStock

$ 35.00 ---ONLY---

SKU: UPS-PRO-700-650VA Categories: COMPUTER PARTS, UPS

GENERAL

Capacity	650VA
Dimension (mm)	286 x 96 x 138 (D x W x H)
Weight (kg)	4.3

INPUT

Voltage Range	162 ~ 290VAC (Single boost) 140 ~ 300VAC (Double boost)
Frequency	50Hz/60Hz (Auto-sensing)
Phase	Single + GND

OUTPUT

Voltage Range	220-240VAC
Battery Mode	220-240VAC
Frequency	50Hz ±1% (Battery mode)
Waveform	Simulated sine wave (Battery mode) Sine wave (AC mode)
Transfer Time	2ms typical

BATTERY

Type	12V/8.2AH x 1
Backup Time	8 – 20 mins depending on load
Recharge Time	2-4 hours recover to 90% capacity

INTERFACE & INDICATORS

Interface	RS232, USB port, RJ45/RJ11 (Optional)
Display	LED/LCD Optional
Alarm	Batt. Mode, low battery, overload, fault, etc.

PROTECTION/MONITORING

Short Circuit Protection	Yes (Line mode & battery mode)
Surge Protection	Yes
Alarm	Audible & Visual
Overload Protection	Line mode : 100 – 120% 1 min change to fault mode >120% change to fault mode immediatelyBattery mode : 100 – 120% 1 min change to fault mode >120% change to fault mode immediately
Intelligent Battery	Prevent overcharging of battery
Management	Protect battery and prolong battery life

Real Panel

1. AC Mode Indicator Green LED Lighting 2. Battery Mode Indicator Battery Normal : Yellow LED Lighting and Blinking every 30s Battery Low : Yellow LED Lighting and Blinking every 2s 3. Overload and Fault Indicator Overload : Red LED Blinking every 2s Fault : Red LED Lighting 4. Power Switch 5. Power AC Input 6. Backup Outlets
