SKU: MZ-V91T0BW

SAMSUNG 990 PRO SSD 1TB PCIe 4.0 M.2 2280 Internal Solid State Hard Drive, Seq. Read Speeds Up to 7,450 MB/s for High End Computing, Gaming, and Heavy Duty Workstations | MZ-V9P1T0BW

Description

🧩 Expert Features

  • PCIe 4.0 Rocket Mode Engaged – Push sequential speeds up to 7,450 MB/s read and 6,900 MB/s write to nearly max out PCIe® 4.0 limits. This is SSD hyperspeed without leaving your motherboard behind.
  • IOPS Overdrive On – Dominate load times with up to 1,200,000 IOPS random read and 1,550,000 IOPS random write, built for gamers, creators, and heavy multitaskers who laugh at loading bars.
  • Power Efficiency Wizardry – Get up to 50% improved performance per watt vs 980 PRO, meaning more speed with less juice — the SSD equivalent of drinking espresso but staying cool.
  • Thermal Mastery – Nickel-coated controller + heatspreader label + Dynamic Thermal Guard = a temperature-taming trifecta that keeps the drive performing ferociously without meltdown.
  • Champion-Ready Gaming Performance – Faster random performance means ultra-quick load times on PS5 and DirectStorage games. Your games don’t just load — they materialize.
  • Samsung Magician Compatible – The ultimate SSD command center for optimisation, health checks, firmware updates, and secure data protection.
  • Built With Samsung Components, End-to-End – V-NAND 3-bit MLC, in-house controller, in-house firmware. True first-party performance from the world’s #1 flash memory brand (since 2003).
  • Console & PC Friendly – Works with client PCs and gaming consoles, ready to drop your load times like they owe you money.

📊 Expert Specs

Category Specification
Model Samsung 990 PRO NVMe M.2 SSD 1TB (MZ-V9P1T0BW)
Rated Capacity 1,000GB (1GB = 1 billion bytes by IDEMA)
Form Factor M.2 (2280)
Interface PCIe Gen 4.0 x4, NVMe 2.0
Storage Memory Samsung V-NAND 3-bit MLC
Controller Samsung In-House Controller
Cache Memory Samsung 1GB Low Power DDR4 SDRAM
Sequential Read Up to 7,450 MB/s
Sequential Write Up to 6,900 MB/s
Random Read (QD32) Up to 1,200,000 IOPS
Random Write (QD32) Up to 1,550,000 IOPS
Random Read (QD1) Up to 22,000 IOPS
Random Write (QD1) Up to 80,000 IOPS
Power Consumption (Avg/Max) Avg 5.4 W / Max 7.8 W
Idle Power Max 50 mW
Voltage 3.3 V ± 5%
MTBF 1.5 Million Hours
Operating Temp 0°C – 70°C
Shock Resistance 1,500 G, 0.5 ms (Half Sine)
Dimensions 80 × 22 × 2.3 mm
Weight Max 9.0g
TRIM Supported
S.M.A.R.T. Supported
Garbage Collection Auto GC Algorithm
Encryption AES 256-bit (Class 0), TCG/Opal, IEEE1667
WWN Support Not Supported
Device Sleep Mode Supported
Application Client PCs, Game Consoles
Software Samsung Magician SSD Management
Installation Kit Not Available
