Samsung 980 PRO 1TB PCIe 4.0 NVMe SSD , Up to 7000 MB/s , NAND Chip Thermal Control , Samsung Magician Software , M.2 2280 Form Factor Internal Solid State Drive (SSD) | MZ-V8P1T0BW
-11%
Samsung 980 PRO 1 TB PCIe NVMe SSD 7000 MBs
Expert Features
Next-level SSD performance
- Unleash the power of the Samsung 980 PRO PCIe 4.0 NVMe SSD for next-level computing. 980 PRO delivers 2x the data transfer rate of PCIe 3.0, while maintaining compatibility with PCIe 3.0.
Maximum Speed
- 980 PRO is raising the bar for NVMe SSDs, delivering read speeds up to 6,900 MB/s. With a PCIe 4.0 interface, it is up to 2x faster than PCIe 3.0 SSDs and up to 12x faster than Samsung SATA SSDs.
- The powerful controller is designed to support larger input & output queues for PCIe 4.0, resulting in electric speeds.
A winning combination
- Designed for hardcore gamers and tech-savvy users, the 980 PRO offers high-performance bandwidth and throughput for heavy-duty applications in gaming, graphics, data analytics, and more. It’s fast at loading games, so you can play more and wait less.
Efficient M.2 SSD
- The 980 PRO comes in a compact M.2 2280 form factor, which can be easily plugged into desktops and laptops.
- Due to its size and thus optimized power efficiency, it’s ideal for building high-performance computing systems.
Reliable thermal control
- High-performance SSDs usually require high-performance thermal control.
- To ensure stable performance, the 980 PRO uses nickel coating to help manage the controller’s heat level and a heat spreader label to deliver effective thermal control of the NAND chip.
Smart thermal solution
- Embedded with Samsung’s cutting-edge thermal control algorithm, 980 PRO manages heat on its own to deliver durable and reliable performance, while minimizing performance fluctuations during extended usage.
Samsung Magician software
- Unlock the full potential of 980 PRO with Samsung Magician’s advanced, yet intuitive optimization tools. Monitor drive health, optimize performance, protect valuable data, and receive important updates with Magician to ensure you’re always getting the best performance out of your SSD.
Expert Specs
Brand | SAMSUNG |
---|---|
Series | 980 PRO |
Model | MZ-V8P1T0BW |
Device Type | Internal Solid State Drive (SSD) |
Used For | Consumer |
Form Factor | M.2 2280 |
---|---|
Capacity | 1 TB |
Memory Components | V-NAND 3-bit MLC |
Interface | PCI-Express Gen 4.0 x4, NVMe 1.3c |
Controller | Samsung Elpis |
Cache | 512MB |
Max Sequential Read | Up to 7000 MBps |
---|---|
Max Sequential Write | Up to 5000 MBps |
4KB Random Read | QD1: Up to 22,000 IOPS QD32: Up to 800,000 IOPS |
4KB Random Write | QD1: Up to 60,000 IOPS QD32: Up to 1,000,000 IOPS |
MTBF | 1,500,000 hours |
Power Consumption (Idle) | Max. 35 mW |
---|---|
Power Consumption (Active) | Average: 5.9W Maximum: 7.4W (Burst mode) |
Operating Temperature | 0°C ~ +70°C |
Max Shock Resistance | 1500G |
Height | 2.38mm |
---|---|
Width | 22.15mm |
Depth | 80.15mm |
Weight | 9.00g |
Description
MZ-V8P1T0BW
Samsung 980 PRO 1 TB PCIe NVMe SSD 7000 MBs
Samsung 980 PRO 1TB PCIe 4.0 NVMe SSD , Up to 7000 MB/s , NAND Chip Thermal Control , Samsung Magician Software , M.2 2280 Form Factor Internal Solid State Drive (SSD) | MZ-V8P1T0BW
