RAM KINGSTON FURY BEAST 16GB 5600MT/s DDR5 RGB DESKTOP KF556C36BBEA-16

$ 68.00 $ 62.00 ---ONLY---
Out stock

Out of stock

SKU: KF556C36BBEA-16 Categories: , ,

KF556C36BBEA-16

DESCRIPTION
SPECIFICATIONS
KF556C36BBEA-16
16GB 2G x 64-Bit
DDR5-5600 CL36 288-Pin DIMM
Continued >>
FEATURES
Kingston FURY KF556C36BBEA-16 is a 2G x 64-bit (16GB)
DDR5-5600 CL36 SDRAM (Synchronous DRAM) 1Rx8, memory
module, based on eight 2G x 8-bit FBGA components per module.
The module supports AMD® EXPO v1.0 and Intel® Extreme
Memory Profiles (Intel® XMP) 3.0. Each module has been
tested to run at DDR5-5600 at a low latency timing of 36-38-38 at
1.25V. The SPDs are programmed to JEDEC standard latency
DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM
uses gold contact fingers. The JEDEC standard electrical
and mechanical specifications are as follows:

CL(IDD)  40 cycles
Row Cycle Time (tRCmin) 48ns(min.)32ns(min.)
Refresh to Active/Refresh
Command Time (tRFCmin)295ns(min.)
Row Active Time (tRASmin)32ns(min.)
UL Rating 94 V – 0
Operating Temperature 0o
C to +85o
C
Storage Temperature  -55o
C to +100o
C

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• Height 1.66” (42.23mm), w/heatsink
