SKU: 911-7E47-021

MSI X870 GAMING PLUS WIFI AM5 ATX Motherboard With AMD X870 Chipset, AM5 Socket, 4x DDR5 8200+ MT/s OC, PCIe 5.0, USB4 40Gbps, Wi-Fi 7, 5G LAN  , for Ryzen 9000 / 8000 / 7000 Series

$ 293.00 ---ONLY---

Description

Expert Features

  • AMD X870 Chipset, AM5 Muscle : Built around the AMD X870 chipset, this motherboard supports AMD Ryzen™ 9000, 8000, and 7000 Series desktop processors, delivering a future-ready AM5 platform for high-performance gaming and content creation.
  • Extreme DDR5 Memory Support : Supports up to 256GB of DDR5 across four DIMM slots, with dual-channel architecture and overclocking speeds reaching DDR5 8200+ MT/s (OC) depending on CPU and memory configuration. AMD EXPO™ and JEDEC profiles are fully supported.
  • Flagship-Grade Power Delivery : A robust 14+2+1 Duet Rail Power System powered by 60A Smart Power Stages, dual CPU power connectors, and an 8-layer PCB with 2oz thickened copper ensures stable power delivery under sustained high loads.
  • PCIe 5.0 And Lightning-Fast Storage : Features a PCIe 5.0 x16 graphics slot and three M.2 slots, including a PCIe 5.0 x4 Lightning Gen 5 M.2, enabling ultra-fast GPUs and NVMe storage.
  • USB4 And Ultra-Fast Connectivity : Equipped with USB4 (40Gbps), USB 20Gbps Type-C, and multiple high-speed USB ports, delivering massive bandwidth for peripherals, displays, and external storage.
  • Next-Gen Networking  : Includes Wi-Fi 7 with MU-MIMO and tri-band support (2.4 / 5 / 6GHz) plus Realtek 5G LAN, ensuring low latency and high throughput for competitive gaming and streaming.
  • FROZR Cooling Design : Extended heatsinks, 7W/mK MOSFET thermal pads, choke pads, and EZ M.2 Shield Frozr II keep thermals under control during 24/7 operation.
  • EZ DIY And AI-Enhanced Control : Features EZ PCIe Clip II, EZ M.2 Clip II, pre-installed I/O shield, EZ Antenna, MSI Click BIOS X, and AI-powered features like Frozr AI Cooling, AI LAN Manager, and AI Boost.

Expert Specs

Category Specification
Chipset AMD X870
CPU Socket AM5
CPU Support AMD Ryzen™ 9000 / 8000 / 7000 Series
Form Factor ATX
Memory Slots 4× DDR5 UDIMM
Max Memory Capacity 256GB
Memory Speed 8200+ MT/s (OC), 5600–4800 MT/s (JEDEC)
Memory Support Dual-Channel, AMD EXPO™, Non-ECC Unbuffered
Expansion Slots 1× PCIe 5.0 x16, 1× PCIe 4.0 x4, 2× PCIe 3.0 x1
Storage 3× M.2 (PCIe 5.0 x4 / PCIe 4.0), 4× SATA 6Gb/s
RAID Support RAID 0/1/5 (M.2 NVMe, CPU dependent)
Graphics Output HDMI™ 2.1, USB-C DisplayPort 1.4
USB Ports USB 2.0, USB 5Gbps, USB 10Gbps, USB 20Gbps, USB4 40Gbps
LAN Realtek® 8126VB 5G LAN
Wireless Wi-Fi 7, Bluetooth® 5.4
Audio Realtek® ALC897 7.1-Channel HD Audio
Power Design 14+2+1 Phase, 60A SPS
Cooling Features Extended Heatsink, M.2 Shield Frozr II
OS Support Windows® 11 64-bit
PCB Dimensions 243.84 × 304.8 mm
