SKU: 912-V536-007

MSI GeForce RTX 5060 Ti 8G Gaming Trio OC With DLSS 4, GDDR7, PCIe 5.0, TRI FROZR 4 Cooling, HDMI 2.1b, DisplayPort 2.1b, 180W TDP, 2662 MHz Boost, 16-Pin ATX 3.1 Power | 1 YEAR WARRANTY

Original price was: $ 500.00.Current price is: $ 474.00. ---ONLY---

OUT OF STOCK

OUT OF STOCK

Description

6 MONTH WRTY

⚙️ Expert Features – For Those Who Game Like It’s Personal

  • Next-Gen Blackwell Architecture: Armed with 5th Gen Tensor Cores and 4th Gen Ray Tracing Cores, you get FP4 AI compute, real-time ray tracing, and insane DLSS 4 frame generation.
  • 8GB GDDR7 Memory at 28Gbps: Peak bandwidth speeds with a 128-bit bus make this a monster for high-res gaming and content creation.
  • Core Clock Boost to 2662 MHz (MSI Center): Pushes every watt to the max with Extreme Performance tuning for serious gamers and render junkies.
  • TRI FROZR 4 Thermal Design: Upgraded fans, copper baseplate, airflow control, and more—all engineered for quieter, cooler, longer-lasting sessions.
  • STORMFORCE Fans: Seven-blade design with claw-texturing and circular arc shape to increase focused airflow with less turbulence.
  • Nickel-Plated Copper Baseplate: GPU heat gets absorbed instantly and moved along faster than a rage quit in a 1v5 clutch.
  • Core Pipes with Square Contact Design: Maximizes thermal transfer from GPU to heatsink by keeping constant, even contact.
  • Wave Curved 4.0 Fins: High-low fin array paired with curved wave edges boosts flow and reduces air drag.
  • Air Antegrade Fin 2.0: Optimized fin stack improves airflow with V-shaped cuts and staggered fin heights for less resistance and more cooling.
  • Metal Backplate with Thermal Pads & Vents: Adds structural strength and passive cooling with built-in vents and heat spreaders.
  • DrMOS Power Stages + Fuse Guards: Efficient, voltage-precise power delivery with built-in protection for those high-load days.
  • MSI Center AI Software: AI tuning, live monitoring, and system optimization—all in one dashboard made for control freaks (in the best way).
  • Afterburner Overclocking: The world’s favorite overclocking app lets you take full manual control like a GPU sorcerer.
  • 16-Pin Power Ready (ATX 3.1 PSU Recommended): PCIe 5.0 support meets next-gen ATX 3.1 spec for peak current delivery and cable neatness.
  • NVIDIA Reflex 2 + G-SYNC + ACE: Smash latency, sync frames, and give digital humans more emotional range than your ex.
  • 8K Ready + Up To 4 Displays: For builders who think four screens is just the beginning.

🧠 Expert Specs – Power, Dimensions, and Ports at a Glance

Category Details
Model Name GeForce RTX™ 5060 Ti 8G GAMING TRIO OC
Product Code G506T-8GTC
GPU Architecture NVIDIA® Blackwell
CUDA® Cores 4608 Units
Core Clock Boost: 2647 MHz
Extreme: 2662 MHz (MSI Center)
Memory 8GB GDDR7, 128-bit, 28 Gbps
Outputs 3 x DisplayPort 2.1b
1 x HDMI 2.1b (4K 480Hz / 8K 120Hz w/ DSC & VRR)
Ray Tracing Support 4th Gen RT Cores With Neural Rendering
DLSS Version NVIDIA DLSS 4 With Multi-Frame Generation
Power Consumption 180W
Power Connector 1 x 16-Pin (ATX 3.1 PSU Recommended)
Recommended PSU 600W
Interface PCIe Gen 5.0 x16 (Runs At x8)
Cooling System TRI FROZR 4, STORMFORCE Fans, Nickel Baseplate, Wave Curved + Antegrade Fins
Backplate Reinforced Metal With Airflow Vents and Thermal Pads
Card Dimensions (mm) 300 x 125 x 44
Weight 839 g (Card) / 1345 g (Boxed)
DirectX / OpenGL DirectX 12 Ultimate / OpenGL 4.6
Max Displays Supported 4
G-SYNC® Compatible Yes
Max Digital Resolution 7680 x 4320 (8K Ready)
Software Suite MSI Center, Afterburner, NVIDIA Broadcast, Studio, Reflex 2, ACE
