SKU: 912-V537-047

MSI GeForce RTX 5060 8G Gaming Trio OC With DLSS 4, GDDR7, PCIe 5.0, TRI FROZR 4 Cooling, HDMI 2.1b, DisplayPort 2.1b, 155W TDP, 2640 MHz Boost, RGB Backplate | 1 YEAR WARRANTY

$ 404.00 ---ONLY---

OUT OF STOCK

OUT OF STOCK

Description

⚙️ Expert Features – Big Performance, Even Bigger Personality

  • NVIDIA Blackwell Architecture: Built for gamers and creators with FP4 Tensor Cores, Neural Shaders, DLSS 4, and 4th Gen Ray Tracing delivering stunning realism and high FPS.
  • 8GB GDDR7 @ 28 Gbps: Blazing memory bandwidth and responsiveness on a 128-bit interface. Game at high res without stutters or bottlenecks.
  • Core Clock Up To 2640 MHz: With MSI Center’s Extreme Mode enabled, this card flexes to deliver serious performance spikes.
  • TRI FROZR 4 Thermal System: A trio of next-gen upgrades—wave fins, antegrade cutouts, and massive heatpipe contact—keep temps down and acoustics stealthy.
  • STORMFORCE Fans: Designed with claw-textured blades and a circular arc for efficient, low-noise airflow that cools like a beast without sounding like one.
  • Nickel-Plated Copper Baseplate: Transfers GPU and memory heat like a pro, straight into the heart of the heatsink for rapid cooling.
  • Core Pipes With Square Contact: Flattened design maximizes contact area with the GPU base for improved thermal transfer.
  • Wave Curved 4.0 Fins + Air Antegrade 2.0: V-shaped airflow cutouts plus high-low fin structure reduce turbulence and optimize flow.
  • Metal Backplate With Thermal Pads: Adds rigidity, airflow vents, and extra passive cooling where it counts most.
  • DrMOS Power Stage + Fuses: Efficient voltage management and built-in fuses protect your system from the wrath of unstable power.
  • Bundled Support Stand: Keeps your card level and steady—especially helpful in vertical cases or ultra-wide towers.
  • MSI Center Software: AI tuning, live system monitoring, and one-click optimization built into an intuitive dashboard.
  • Afterburner Overclocking: Get full control over clocks, fan curves, and voltages using the most trusted OC software on Earth.
  • PCIe 5.0 Interface (x8 Lanes): Delivers next-gen bandwidth and future-ready performance with high compatibility.
  • Full NVIDIA Suite: Reflex 2, ACE, Studio, G-SYNC, Broadcast, and 9th-gen encoding give gamers, streamers, and creators everything they need.

📊 Expert Specs – The Numbers Don’t Lie

Category Details
Model Name GeForce RTX™ 5060 8G GAMING TRIO OC
Product Code G5060-8GTC
GPU Architecture NVIDIA® Blackwell
CUDA® Cores 3840 Units
Core Clock Boost: 2625 MHz
Extreme: 2640 MHz (MSI Center)
Memory 8GB GDDR7, 128-bit, 28 Gbps
Outputs 3 x DisplayPort 2.1b
1 x HDMI 2.1b (4K 480Hz / 8K 120Hz with DSC, VRR)
Ray Tracing Support 4th Gen Cores With Neural Rendering
DLSS Version NVIDIA DLSS 4 With Multi-Frame Generation
Power Consumption 155W
Power Connector 1 x 8-Pin
Recommended PSU 550W
Interface PCIe Gen 5.0 x16 (Runs At x8)
Cooling System TRI FROZR 4, STORMFORCE Fans, Copper Baseplate, Core Pipes, Dual Fins
Backplate Metal With Thermal Pads And Airflow Vents
Support Stand Included, Case Compatibility Required
Card Dimensions (mm) 300 x 125 x 44
Weight 797 g (Card) / 1206 g (Boxed)
DirectX / OpenGL DirectX 12 Ultimate / OpenGL 4.6
Max Displays Supported 4
G-SYNC® Compatible Yes
Max Digital Resolution 7680 x 4320 (8K Ultra HD)
Software Suite MSI Center, Afterburner, NVIDIA Studio, Broadcast, Reflex 2, ACE
