LENOVO AI-Powered Legion 5 16IRX9 Intel® Core™ i7-14650HX| 16GB DDR5 RAM ; 512GB SSD | RTX™ 4060 , 8GB | 16″ WQXGA IPS Display 165Hz | 4-Zone RGB Backlit Keyboard | Windows® 11 | Luna Grey | 1 YEAR WARRANTY
Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 BRAND NEW – 1 YEAR WARRANTY
Expert Briefings
- Processor : Intel® Core™ i7-14650HX, 16C (8P + 8E) / 24T, P-core 2.2 / 5.2GHz, E-core 1.6 / 3.7GHz, 30MB
- AI PC Category : AI-Powered Gaming PC
- Graphics : NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS
- Memory : 16GB SO-DIMM DDR5-5600 ; Two DDR5 SO-DIMM slots, dual-channel capable Upgradable up to 64GB DDR5-5600 Max Memory
- Storage : 512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®
- Display : 16″ WQXGA (2560×1600) IPS 350nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision®, G-SYNC®, Low Blue Light
- Keyboard : 4-Zone RGB Backlit, English (US)
- Outer Case : Luna Grey ; 359.7 x 262.3 x 19.7-25.2 mm ; 2.36 kg
- Operating System : Windows® 11 Home, English
- CONNECTIVITY : 100/1000M (RJ-45) Ethernet | WLAN + Bluetooth Wi-Fi® 6E, 802.11ax 2×2 + BT5.2
EXTRAS
- microSD Card Reader
- High Definition (HD) Audio, Realtek® ALC3287 codec
- Stereo speakers, 2W x2, optimized with Nahimic Audio
- FHD 1080p Camera with E-shutter
- 2x Array Microphone
- Integrated 80Wh Battery
- 230W Slim Tip (3-pin) Power Adapter
- LA1 AI Chip
Standard Ports
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Card reader
- 1x Power connector
LENOVO AI-Powered Legion 5 16IRX9 Intel® Core™ i7-14650HX| 16GB DDR5 RAM ; 512GB SSD | RTX™ 4060 , 8GB | 16″ WQXGA IPS Display 165Hz | 4-Zone RGB Backlit Keyboard | Windows® 11 | Luna Grey | 1 YEAR WARRANTY
EXPERT SPECS
| PERFORMANCE | |
| Processor |
Intel® Core™ i7-14650HX, 16C (8P + 8E) / 24T, P-core 2.2 / 5.2GHz, E-core 1.6 / 3.7GHz, 30MB
|
| AI PC Category |
AI-Powered Gaming PC
|
| Graphics |
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS
|
| Chipset |
Intel® HM770 Chipset
|
| Memory |
1x 16GB SO-DIMM DDR5-5600
|
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable
|
| Max Memory |
Up to 64GB DDR5-5600
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®
|
| Storage Support |
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB
|
| Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
| Card Reader |
microSD Card Reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
| Speakers |
Stereo speakers, 2W x2, optimized with Nahimic Audio
|
| Camera |
FHD 1080p with E-shutter
|
| Microphone |
2x, Array
|
| Battery |
Integrated 80Wh
|
| Power Adapter |
230W Slim Tip (3-pin)
|
| Special Features |
AI Chip: LA1
|
| DESIGN | |
| Display |
16″ WQXGA (2560×1600) IPS 350nits Anti-glare, 100% sRGB, 165Hz, Dolby Vision®, G-SYNC®, Low Blue Light
|
| Touchscreen |
None
|
| Color Calibration |
Factory Color Calibration
|
| Keyboard |
4-Zone RGB Backlit, English (US)
|
| Touchpad |
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
|
| Case Color |
Luna Grey
|
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting)
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Dimensions (WxDxH) |
359.7 x 262.3 x 19.7-25.2 mm (14.16 x 10.33 x 0.78-0.99 inches)
|
| Weight |
Around 2.36 kg (5.2 lbs)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Home, English
|
| Bundled Software |
Office Trial
|
| CONNECTIVITY | |
| Ethernet |
100/1000M (RJ-45)
|
| WLAN + Bluetooth |
Wi-Fi® 6E, 802.11ax 2×2 + BT5.2
|
| Standard Ports |
|
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0 Enabled
|
| Fingerprint Reader |
None
|
| Other Security |
E-shutter
|
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
None
|
| ACCESSORIES | |
| Bundled Accessories |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| Other Certifications |
TÜV Rheinland® Low Blue Light (Hardware Solution)
|
Description
83DG004NUS
Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11
LENOVO AI-Powered Legion 5 16IRX9 Intel® Core™ i7-14650HX| 16GB DDR5 RAM ; 512GB SSD | RTX™ 4060 , 8GB | 16″ WQXGA IPS Display 165Hz | 4-Zone RGB Backlit Keyboard | Windows® 11 | Luna Grey | 1 YEAR WARRANTY
AI-Powered Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 16″ Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11 Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11
https://psref.lenovo.com/Detail/Legion_5_16IRX9?M=83DG004NUS
Legion 5 i7-14650HX RTX 4060 16GB RAM Win 11
