E1-600 NON-MODULAR 600W PSU

EXPERT FEATURES

• Support C6/C7 Power States & Meets 80% Efficiency : The HELIOS E1-600W can deliver up to 80%+ efficiency reliably while automatically adjusting its fan speed according to temperature.
• EXTRAORDINARY EFFICIENCY WITH 620mm EPS Cable : HELIOS E1-600W can perfectly draw power at 80% efficiency while releasing minimal heat. With less heat generated, less noise arises.
• Stealth Black :  The stealthy PSU provides durability and luxury while being exceptionally economically competent.
• SMART VENTILATION : The power supply unit supports automatic fan speed optimization which adjusts its fan speed according to the temperature and load

EXPERT SPECIFICATION

• Model : HELIOS E1-600
•  POWER Type : ATX12V v2.4
• Efficiency : Meeting up to 80% efficiency
• Support MB Sync : No
• Dimension (L x W x H) : 140 x 150 x 86 mm
• Support C6/C7 power state : Yes
• AC Input : 220-240V / 6A / 47-63Hz
• DC Output : +3.3V / +5V / +12V / -12V / +5Vsb
• Max. Output Current : 16A / 16A / 40.5A / 0.3A / 2.5A
• Max. Output Power : 100W / 486W / 3.6W / 12.5W
• Total Power : 600W
• Protection : OVP / UVP / OPP / SCP
• Main Power : 1 (20+4 Pin)
• CPU : 1 (4+4 Pin)
• PCI-E : 2 (6+2 Pin)
• SATA : 5 (5 Pin)
• Molex : 2 (4 Pin)
• Floppy : 1 (4 Pin)
• Modular : Non Modular
• Silent Mode : No
• DC to DC : No
