DeepCool PL650D ATX3.0 650W PSU 80 PLUS BRONZE ; ATX12V V3.0 with Native PCIe 5.0 Power Connector rated for 300W; Hydro Bearing 120mm Fan ; Full Protection OPP, OVP, SCP, OTP …etc ; Non-Modular | BLACK
-12%
DeepCool PL650D 650W PSU 80 PLUS BRONZE
PL650D Power Supply Features: Power Up Your Gaming Experience!
- NATIVE ATX3.0: Fully compliant with Intel’s ATX3.0 standard, delivering double the total system power for 0.1 ms—say goodbye to power spikes! Includes a PCIe 5.0 connector rated for 300W.
- PREMIUM ELECTROLYTIC CAPACITORS: High-grade capacitors ensure ≥ 16 ms hold-up time under full load, making those pesky power outages a non-issue!
- ROCK SOLID RELIABILITY: Features a dual-transistor forward topology with active PFC and DC-to-DC conversion. Built with top-notch parts, it operates at altitudes up to 5,000 meters!
- PAST, PRESENT, AND FUTURE: Comes with three PCIe, two EPS, and a 16AWG 12VHPWR cable—providing consistent power for legacy and next-gen PCs alike.
- BOLD BRONZE: Certified 80 PLUS Bronze, ensuring at least 85% efficiency under typical loads. This PSU doesn’t just perform; it excels!
PEACE OF MIND: Packed with essential safeguards: OPP, OVP, SCP, OTP, OCP, UVP, SIP, and NLO. Your power supply’s got your back!
-
- Over Power Protection: Keeps your system safe when things get intense.
- Over Voltage Protection: Prevents electrical shocks to your gear.
- Short Circuit Protection: No more meltdowns during your epic battles!
- Over Temp Protection: Stays cool even in high-stakes situations.
- Over Current Protection: Manages those crazy power surges.
- Under Voltage Protection: Ensures your system never runs low on juice.
- Surge & Inrush Protection: Your power supply’s superhero cape!
- No Load Operation: Perfectly chill when not in use.
Connector Bonanza:
- Main Power Connector (20+4) Pin x 1: For that all-important motherboard connection!
- CPU (4+4) Pin x 2: Power up your CPU like a champ!
- PCI-E (6+2) Pin x 1: Perfect for your graphics card.
- PCI-E (6+2) Pin x 2: Double the connection for those GPU upgrades!
- 12VHPWR (16Pin) x 1: The future-proof connection you need!
- SATA x 4 + 4Pin Peripheral x 1: Because storage is life!
Get ready to power up and dominate the gaming world with the PL650D! Your rig deserves the best! 🎮⚡
Expert Specs
| Type | ATX12V V3.0 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| Efficiency certification | 80Plus Bronze |
| Fan Size | 120mm |
| Fan Bearing | HYB(Hydro Bearing) |
| Topology | Active PFC+DC to DC |
| Capacitors | Chinese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms |
| Efficiency | ≥85% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0 – 40℃ |
| Regulatory | CE/FCC/CCC/RCM/EAC/BIS/ CAN ICES-003(B)/NMB-003(B) /TUV-RH |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/中国 RoHS/Triman/P65 |
| MTBF | 100,000 Hours |
Description
R-PL650D-FC0B-EU
DeepCool PL650D 650W PSU 80 PLUS BRONZE
DeepCool PL650D ATX3.0 650W PSU 80 PLUS BRONZE ; ATX12V V3.0 with Native PCIe 5.0 Power Connector rated for 300W; Hydro Bearing 120mm Fan ; Full Protection OPP, OVP, SCP, OTP …etc ; Non-Modular | BLACK
DeepCool PL650D 650W PSU 80 PLUS BRONZE DeepCool PL650D 650W PSU 80 PLUS BRONZE DeepCool PL650D 650W PSU 80 PLUS BRONZE DeepCool PL650D 650W PSU 80 PLUS BRONZE
