CPU Intel Core i7-14700F – Core i7 14th Gen Raptor Lake 20-Core (8P+12E) 28 threads , Up to 5.4 GHz Unlocked , 33MB Cache, LGA 1700 65W None Integrated Graphics Processor | TRAY

$ 366.00 Original price was: $ 366.00.$ 355.00Current price is: $ 355.00. ---ONLY---
-3%
SKU: I7-14700F-TRAY Categories: ,

CPU Intel Core i7 14700F 14th Gen – TRAY

Expert Features

  • 20 cores (8 P-cores + 12 E-cores) and 28 threads
  • Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance
  • Up to 5.4 GHz unlocked. 33MB Cache
  • Compatible with Intel 600-series (with potential BIOS update) and 700-series chipset-based motherboards
  • PCIe 5.0 & 4.0 support. DDR4 and DDR5 Memory support. RM1 thermal solution included. Discrete graphics required.

Expert Specs

Model

Brand Intel
Processors Type Desktop
Series Core i7 14th Gen
Name Core i7-14700F
Model BX8071514700F

Details

CPU Socket Type LGA 1700
Core Name Raptor Lake
# of Cores 20-Core (8P+12E)
# of Threads 28-Threads
Operating Frequency
  • Performance-core Base Frequency: 2.1 GHz
  • Efficient-core Base Frequency: 1.5 GHz
Max Turbo Frequency
  • Max Turbo Frequency: 5.4 GHz
  • Intel® Turbo Boost Max Technology 3.0 Frequency: 5.4 GHz
  • Performance-core Max Turbo Frequency: 5.3 GHz
  • Efficient-core Max Turbo Frequency: 4.2 GHz
L2 Cache 28MB
L3 Cache 33MB
Manufacturing Tech Intel 7
64-Bit Support Yes
Hyper-Threading Support Yes
Memory Types DDR4 3200 / DDR5 5600
Memory Channel 2
Max Memory Size 192 GB
Max Memory Bandwidth 89.6 GB/s
Virtualization Technology Support Yes
Integrated Graphics None Integrated Graphics
Scalability 1S Only
PCI Express Revision 5.0 / 4.0
PCI Express Configurations Up to 1×16+4, 2×8+4
Max Number of PCI Express Lanes 20
Thermal Design Power 65W
Max Turbo Power 219W
Cooling Device Intel Laminar RM1 included
Compatible Desktop Chipsets Intel H610 / Intel H670 / Intel B660 / Intel Q670 / Intel W680 / Intel Z690 / Intel H770 / Intel B760 / Intel Z790
* BIOS update may be required when used with some old chipset motherboard
Operating System Supported Linux / Windows 10 (22H2, 21H2) / Windows 11 (22H2, 21H2)

Description

I7-14700F-TRAY

CPU Intel Core i7 14700F 14th Gen

CPU Intel Core i7-14700F – Core i7 14th Gen Raptor Lake 20-Core (8P+12E) 28 threads , Up to 5.4 GHz Unlocked , 33MB Cache, LGA 1700 65W None Integrated Graphics Processor
